Graco K30FW0 King 30:1 Sprayer, Integrated Filter, Wall Mount, Air Controls, Siphon Kit
The Graco K30FW0 is supplied in the following configuration: King 30:1 Sprayer, Integrated Filter, Wall Mount, Air Controls, Siphon Kit.
Specifications
- Manufacturer: Graco
- Manufacturer Part Number: K30FW0
- UPC: 755652706601
- Height: 30 IN | 76.200 CM
- Length: 56 IN | 142.240 CM
- Width: 25 IN | 63.500 CM
- Volume: 24.306 FT3 | 0.688 M3
- Shipping Weight: 282 LBS | 127.913 KG
- Approved for Hazardous Locations: Yes
- Convertible: Non-Convertible
- Frame Configuration: Wall Mount
- Gun Model: No Applicator
- Includes: Pump, Lower, Motor, Standard Filter, Wall Mount Bracket, Air Controls, Siphon Kit
- Lower Type: Integrated Filter
- Material Application: Paints, Primers
- Fluid Outlet Size (mm): 12.7
- Maximum Tip Size (in): Variable
- Fluid Inlet Size (mm): 31.75
- Fluid Inlet Size (in): 1-1/4
- Maximum Working Pressure (psi): 3150
- Maximum Air Inlet Pressure (psi): 150
- Maximum Sound Pressure Level (dB(A)): 81.48
- Maximum Working Pressure (bar): 217
- Maximum Working Pressure (kPa): 21700
- Maximum Working Pressure (MPa): 21.7
- Model: King
- Weight (kg): 89
- Product Type: Single Leg
- Package Pressure Ratio (Motor/Lower): 30:1 XL3400 / 220cc
- Pump Mount Type: Wall Mount
- Pump Rod Type: MaxLife
This is a special order part. Please allow up to 7 business days after the order has been placed before the order will ship. Orders will only ship complete once all items are in stock. Stock is dependent on Graco's current availability at the time of purchase. If the order can not be shipped within the 7 days, an email will be sent alerting you of any delays or backorders. Prop 65 Warning! This product can expose you to chemicals which are known to the State of California to cause cancer.
Product images are for illustrative purposes only.
