Flex Plus Airless Spray Gun
The Flex Plus Airless Spray Gun is designed for demanding applications including line striping, heavy coatings, and joint compounds. Includes a 2-finger trigger, RAC 5 LineLazer SwitchTip, and tip guard.
Maximized Flow for Heavier Coatings
-
Airless hose bypasses the handle and connects directly to the gun
-
Large fluid flow capacity for heavier materials
-
Spring guard provides additional hose support
No-Adjustment Needle
-
Simplifies maintenance
-
Allows quick and easy repairs
Patented Needle Design
-
Designed for increased service life and durability
Large Fluid Path
-
Improves material flow
-
Helps reduce clogging when spraying heavier coatings
| Specification | Details |
|---|---|
| Model | Flex Plus |
| Product Type | Airless Spray Gun |
| UPC | 633955035997 |
| Country of Origin | USA |
| Air Inlet | 1/4 in (6.35 mm), Male |
| Component A Inlet | 1/4 in NPSM |
| Fluid Orifice | 2.29 mm |
| Max. Fluid Pressure | 5,000 psi (345 bar) |
| Max. Fluid Temperature | 120°F (50°C) |
| Trigger | Two-Finger |
| Trigger Lock | Locking |
| Gun Weight | 1.125 lb (0.51 kg) |
| Sound Pressure Level | 78 dB(A) |
| Dimensions (L × W × H) | 8.55 × 11.4 × 3.8 in |
| Shipping Weight | 1.96 lb (0.889 kg) |
| For Use With | Airless spraying, line striping, LineLazer III 3900/5900 |
| Includes | 235474 Repair Kit, RAC 5 LineLazer 319 Tip, RAC X Guard |
This is a special order part. Please allow up to 7 business days after the order has been placed before the order will ship. Orders will only ship complete once all items are in stock. Stock is dependent on Graco's current availability at the time of purchase. If the order can not be shipped within the 7 days, an email will be sent alerting you of any delays or backorders.
Prop 65 Warning!
This product can expose you to chemicals which are known to the State of California to cause cancer.
